MAIN APPLICATION
WLM super fine machine is made up of three parts: main machine, auxiliary machine and electric control box. It has the properties of wind selection, having no sieve or net, and an even granularity of the processed material.The production process going on continuously, the machine can undertake the grinding of chemical products. food medcine, medicament, cosmetics, plastic, dyestuff, resin, cotourant, grain, etc.
MACHINE DESCRIPTION
1) Simple structure , easy in installation and maintenance.
2) Adopting advanced world famous brand motor ,electric parts,bearing and operation parts.
3) No dust during production, and dust can be collected in dust collecting box.
4) No need screen, particle size can be changed by change speed; particle size varies from 80 to 600 mesh.
5) Around mill chamber and bearing, there is water-cooling jacket to cool the machine.
TECHNICAL PARAMETERS
|
Model |
WLM-10 |
WLM-15 |
WLM-20 |
WLM-30 |
WLM-60 |
WLM-80 |
WLM-100 |
|
Production Capacity (kg) |
10~50 |
50~100 |
80~200 |
200~400 |
400~800 |
500~1000 |
600~1200 |
|
Feeding size (mm) |
<5 |
<10 |
<10 |
<12 |
<12 |
<12 |
<12 |
|
Crushing fineness (mesh) |
80-600 |
||||||
|
Motor power (kw) |
12 |
13.37 |
18.37 |
42.5 |
77.5 |
96 |
138 |
|
Spindle speed (rpm) |
4000 |
5800 |
4200 |
3800 |
3200 |
2800 |
2000 |
|
Weight (kg) |
500 |
1000 |
1200 |
1800 |
2500 |
3000 |
4000 |
|
Overall dimension (L*W*H)(mm) |
1700x1800x2200 |
4500x1250x2700 |
6000x1250x2900 |
7100x1300x3650 |
8000x2300x4500 |
8500x2500x4600 |
10000x2800x5000 |
COMPANY ADVANTAGE
1. Real factory- We Real and expert factory, welcome you video call anytime to Verify our factory authenticity.
2. High quality-We have fixed suppliers of raw materials,our material is newest and good quality,our workers have rich experience,so we can guarantee the best quality.
3. Real factory- We Real and expert factory, welcome you video call anytime to Verify our factory authenticity.
4. High quality-We have fixed suppliers of raw materials,our material is newest and good quality,our workers have rich experience,so we can guarantee the best quality.
